Outlet elbow S/A for monitors StreamMaster 3578-3579
Maintenance/repair part: outlet elbow sub-assembly for monitors StreamMaster 3578 and 3579 with bosses [moulded mounting bracket (4 threaded holes)].
O-RING 757295 2-110
O-ring for AKRON mechanisms 757295 2-110.
Gears: lifting mechanism for monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
44 |
- |
PLANETARY GEAR RING |
1 |
|
52 |
- |
SHOULDER SLEEVE |
8 |
|
53 |
- |
HEXAGONAL SOCKET HEAD CAP SCREW WITH SHOULDER |
8 |
|
90 |
- |
AXIS OF ROTATION |
1 |
|
91 |
- |
PLANETARY GEAR |
8 |
|
92 |
- |
DRIVE SUPPORT |
1 |
|
93 |
- |
SHOULDERED SPACER |
1 |
10-TOOTH PINION 769499 X1/2 BORE X35
10-tooth sprocket for AKRON mechanisms 769499 X1/2 BORE X35.
6052 controller for monitor StreamMaster II
6052 controller module for StreamMaster II firefighting monitor (3480 and 3482 models).
Repair kit: position sensor for worm gear - monitor Stream Master II (3480-3482)
Detailed content :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
65 |
- |
WORM WHEEL |
1 |
|
66 |
34523 |
|
1 |
|
67 |
- |
MAGNET |
1 |
O-RING SEAL 2-120
To access the individual parts, please refer to the interactive table in the KIT CONTENTS tab
NICKEL MAGNET 731081 1/4D X 1/4LG
Nickel magnet for AKRON mechanisms 731081 1/4D X 1/4LG.
CHROME-PLATED WORM GEAR .189 118528
Chrome-plated steel worm screw for AKRON 118528 mechanisms.
