Belt drive for rotation system - monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
39414 |
|
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
2 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
|
100 |
39412 |
ELEVATION STOP |
2 |
NOTCHED PULLEY SHAFT
O-RING 2-112
NEEDLE BEARINGTo access the individual parts, please refer to the interactive table on the KIT CONTENTS
Washer 784072 7/16x.200x.031
Stainless steel washer for AKRON mechanisms 784072 10 ST STL 7/16 X .200X .031T
O-ring 757058 (1-7/8 x 1-11/16) - 2-131
Nitrile rubber O-ring for AKRON mechanisms 757058: 1 7/8 X 1 11/16 2-131
Narrow washer 784123 3/8 x .188
Stainless steel narrow washer for AKRON mechanisms 784123 88 SS NARROW 3/8 X .188 X
10-TOOTH PINION 769499 X1/2 BORE X35
10-tooth sprocket for AKRON mechanisms 769499 X1/2 BORE X35.
SHAFT FOR ROTATION MECHANISM 769497 303-304ST
Rotating shaft for AKRON mechanisms 769497 303-304ST.
Wiring Harness for StreamMaster 3578, 3579, and 3598 (U1) monitors
Complete wiring harness (ITT, SpeedClip, and Deutsch connectors) with stow/storage position for the following U1 monitor models:
- StreamMaster 3578, 3579, and 3598
BE SURE TO CHECK THE HARNESS'S COMPATIBILITY WITH YOUR Monitor
Rotation mechanism 3578-0201 - 5:1 planetary gear (12 teeth)
AKRON 3578-0201 rotation sub-assembly - complete system with 2 planetary gear plates (5:1 - 12 teeth) and rotation shaft for monitor StreamMaster XT 3598 (including U2 version).
