Base inlet adapter for classic ladder pipe 1496
Maintenance/repair part: base inlet adapter 109841 for classic ladder pipe 1496.
Hex socket set screw with cone point 765186 3/8-24 x 1/2
Stainless steel hex socket set screw with cone point for AKRON mechanisms 765186 3/8-24 x 1/2.
O-ring 757260 - 2-012
Carboxylated nitrile rubber O-ring for AKRON mechanisms 757260 CARBOXILATED NITRILE N1090 2-012
Elevating mechanism - monitor StreamMaster II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
36 |
34397 |
|
1 |
|
37 |
32804 |
|
4 |
|
38 |
33649 |
|
2 |
|
39 |
34478 |
|
1 |
|
40 |
34839 |
|
1 |
|
42 |
- |
hexagon socket head cap screw |
4 |
|
49 |
- |
shutter |
1 |
|
50 |
- |
teflon-shouldered spacer |
1 |
|
58 |
34279 |
|
1 |
spring washer
thrust washer
stop
half-moon key
hardened steel worm screw
O-RING 2-112To access the individual parts, please refer to the interactive table on the KIT CONTENTS
Position sensor 34630228
Position sensor (Deutsch plug) for monitors AKRON DeckMaster 3440 (U1), FireFox 3463 and StreamMaster I (3578 and 3579).
Actuator 51772021 (with 24V motor)
Actuator 51772021 U2 24V motor (Deutsch female connector) for monitor nozzles AKRON AkroMatic Styles 5175 and 5177.
TEFLON BEARING SEAL 803058 4.835
Teflon bearing seal for AKRON mechanisms 803058 UHMW 4.835 ID.
RING GEAR FOR ELEVATION 718164
Planetary gear for AKRON 718164 lifting mechanism.
