Hex socket set screw with dog point 767088 10-24 x 5/166
Stainless steel hex socket set screw with dog point for AKRON mechanisms 767088 10-24 x 5/166.
Gears: lifting mechanism for monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
44 |
- |
PLANETARY GEAR RING |
1 |
|
52 |
- |
SHOULDER SLEEVE |
8 |
|
53 |
- |
HEXAGONAL SOCKET HEAD CAP SCREW WITH SHOULDER |
8 |
|
90 |
- |
AXIS OF ROTATION |
1 |
|
91 |
- |
PLANETARY GEAR |
8 |
|
92 |
- |
DRIVE SUPPORT |
1 |
|
93 |
- |
SHOULDERED SPACER |
1 |
Inlet connector for firefighting monitor Apollo
Maintenance/repair part: inlet connector with drilled lugs (locking pin fixing) 104404 for adaptation to mounting flange - firefighting monitors Apollo 3414, 3416, 3421 and 3423.
Position sensor 33520003
Position sensor (ITT Sure-Seal plug) for AKRON roof and bumper turrets TuckAway 3352, 3353, 3354 and 3355.
O-ring 757078 (4-7/8 x 4-5/8) - 2-247
Nitrile rubber O-ring for AKRON mechanisms 757078 : 4 7/8 X 4 5/8 2-247
Elevating mechanism - monitor StreamMaster II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
36 |
34397 |
|
1 |
|
37 |
32804 |
|
4 |
|
38 |
33649 |
|
2 |
|
39 |
34478 |
|
1 |
|
40 |
34839 |
|
1 |
|
42 |
- |
hexagon socket head cap screw |
4 |
|
49 |
- |
shutter |
1 |
|
50 |
- |
teflon-shouldered spacer |
1 |
|
58 |
34279 |
|
1 |
spring washer
thrust washer
stop
half-moon key
hardened steel worm screw
O-RING 2-112To access the individual parts, please refer to the interactive table on the KIT CONTENTS
O-RING 757312 2-036
Nitrile rubber O-ring for AKRON N 2-036 mechanisms.
Square cut gasket 715016 (2-29/32 x 2-3/64)
Nitrile rubber gasket (square-section ring) for AKRON mechanisms 715016 : 2 29/32 X 2 3/64 - V 671
