24V motor for 3293 and 5177 nozzles
24V motor (Deutsch female connector) for AKRON AkroMatic 5177 and Forestry 3293 firehead models.
SHIM WASHER 769494 STL.010
Lock washer for AKRON mechanisms 769494 STL.010.
Repair kit: position sensor for worm gear - monitor Stream Master II (3480-3482)
Detailed content :
Part no |
Ref. MMF |
Designation |
Quantity included |
65 |
- |
WORM WHEEL |
1 |
66 |
34523 |
|
1 |
67 |
- |
MAGNET |
1 |
To access the individual parts, please refer to the interactive table in the KIT CONTENTS tab
Rotation motor for firefighting monitors StreamMaster II 3480-3482
24V motor (Deutsch male connector) for rotation system of firefighting monitors AKRON StreamMaster II 3480 and 3482 models.
Rotating mechanism for monitor Stream Master II (3480-3482)
Detailed contents :
Part no |
Ref. MMF |
Designation |
Quantity included |
35 |
- |
TEFLON SPACER |
1 |
36 |
34397 |
|
1 |
37 |
32804 |
4 |
|
38 |
33649 |
2 |
|
39 |
34478 |
1 |
|
40 |
34839 |
1 |
|
42 |
- |
SOCKET HEAD CAP SCREW |
4 |
43 |
32790 |
1 |
|
47 |
- |
TEFLON WORM SCREW |
1 |
48 |
34521 |
1 |
|
49 |
- |
OBTURATOR |
1 |
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
SHAFT FOR ROTATION MECHANISM 769497 303-304ST
Rotating shaft for AKRON mechanisms 769497 303-304ST.
BRONZE-SHOULDERED SPACER 703461
Shoulder spacer in bronze for AKRON 703461 mechanisms.
Gears: lifting mechanism for monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
Part no |
Ref. MMF |
Designation |
Quantity included |
44 |
- |
PLANETARY GEAR RING |
1 |
52 |
- |
SHOULDER SLEEVE |
8 |
53 |
- |
HEXAGONAL SOCKET HEAD CAP SCREW WITH SHOULDER |
8 |
90 |
- |
AXIS OF ROTATION |
1 |
91 |
- |
PLANETARY GEAR |
8 |
92 |
- |
DRIVE SUPPORT |
1 |
93 |
- |
SHOULDERED SPACER |
1 |
To access the individual parts, please refer to the interactive table in the 'KIT CONTENTS' tab ('Find out more' button below)
