Base inlet adapter for classic ladder pipe 1496
Maintenance/repair part: base inlet adapter 109841 for classic ladder pipe 1496.
Drive mechanism with belt for elevation system - monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
55 |
- |
TEFLON SHOULDERED SPACER |
1 |
|
88 |
39151 |
|
1 |
|
94 |
- |
Notched pulley axle |
1 |
|
95 |
- |
pOULIE wheel |
1 |
|
96 |
- |
BELT |
1 |
O-RING SEAL 2-154To access the individual parts, please refer to the interactive table on the KIT CONTENTS
Hex socket set screw with dog point 767088 10-24 x 5/166
Stainless steel hex socket set screw with dog point for AKRON mechanisms 767088 10-24 x 5/166.
O-ring 757058 (1-7/8 x 1-11/16) - 2-131
Nitrile rubber O-ring for AKRON mechanisms 757058: 1 7/8 X 1 11/16 2-131
Hex socket set screw with cup point 765042 8-32 X 3/16
Stainless steel hex socket set screw with cup point for AKRON mechanisms 765042 8-32 X 3/16.
O-RING 757244 2-030
O-ring for AKRON mechanisms 757244 1 3/4 X 1 5/8. 2-030 N-818-70 IMP.
Wiring harness for Akron tethered controller (U2 CAN network)
This CAN bus wiring harness (COMM3462 U2) is used to connect a tethered controller to an Akron monitor (in configurations with a single controller).
BE SURE TO CHECK THAT THE HARNESS IS COMPATIBLE WITH YOUR Monitor
Drive mechanism with belt for rotation system - monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
- |
NOTCHED PULLEY SHAFT |
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
1 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
O-RING 2-112
NEEDLE BEARING
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
