Rotation mechanism 3578-0201 - 5:1 planetary gear (12 teeth)
AKRON 3578-0201 rotation sub-assembly - complete system with 2 planetary gear plates (5:1 - 12 teeth) and rotation shaft for monitor StreamMaster XT 3598 (including U2 version).
Hardened steel worm 784129 H1076-R
Hardened steel 8-pitch worm gear for AKRON mechanisms 784129 BOSTON H1076-R
O-ring 757471 - 2-349
Viton rubber O-ring for AKRON mechanisms 757471: ELEV VITON 70 DURO 2-349
Gears: rotation mechanism for monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
46 |
- |
AXIS OF ROTATION |
1 |
|
47 |
- |
TEFLON WORM SCREW |
1 |
|
48 |
34521 |
|
1 |
|
51 |
39138 |
7:1 PLANETARY GEAR |
3 |
|
52 |
- |
SHOULDER SLEEVE |
4 |
|
53 |
- |
HEXAGONAL SOCKET HEAD CAP SCREW WITH SHOULDER |
3 |
|
54 |
- |
PLANETARY GEAR RING |
1 |
|
55 |
- |
TEFLON SHOULDER SPACER |
1 |
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
SHAFT FOR ROTATION MECHANISM 769497 303-304ST
Rotating shaft for AKRON mechanisms 769497 303-304ST.
Wiring harness for Akron tethered controller (U2 CAN network)
This CAN bus wiring harness (COMM3462 U2) is used to connect a tethered controller to an Akron monitor (in configurations with a single controller).
BE SURE TO CHECK THAT THE HARNESS IS COMPATIBLE WITH YOUR Monitor
24V (5:1) motor for firefighting monitors FireFox and StreamMaster - repair kit
Repair kit for firefighting monitors Akron FireFox and StreamMaster including 24V motor (ITT male connector), 5:1 ratio, with 2 O-rings.
Compatible with the following AKRON firefighting monitors models:
- FireFox 3463
- StreamMaster I 3578, 3579 and 3598
O-ring 757063 (2-5/8 x 2-1/2) - 2-037
Nitrile rubber O-ring for AKRON mechanisms 757063: 2 5/8 X 2 1/2 2-037
