Belt drive for rotation system - monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
39414 |
|
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
2 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
|
100 |
39412 |
ELEVATION STOP |
2 |
NOTCHED PULLEY SHAFT
O-RING 2-112
NEEDLE BEARINGTo access the individual parts, please refer to the interactive table on the KIT CONTENTS
O-ring kit 92210001 for StreamMaster 3578-3579-3598
Kit of AKRON nitrile rubber O-rings 92210001 for the maintenance of firefighting monitors StreamMaster (3578, 3579 and 3598 models)
PIERCED SCREW CAP 742123 1/2 -20X1/4
Celcon Delrin screw-on drilled plug for AKRON mechanisms 742123 1/2-20 X 1/4.
O-RING 757126 2-231
Nitrile rubber O-ring for AKRON mechanisms 757126 2 7/8 X 2 5/8 2-231.
O-RING PARKER BUNA 757358 2-154
Nitrile rubber O-ring for AKRON mechanisms 757358 N70 2-154.
O-ring 757054 (1-3/8 x 1-3/16) 2-123
Nitrile rubber O-ring for AKRON mechanisms 757054: 1 3/8 X 1 3/16 BUNA N70 2-123
NEEDLE BEARING 704395 1/2ID INASCE86
Needle roller bearing for AKRON 1/2ID INASCE86 mechanisms.
O-RING 757073 2-242
Nitrile rubber O-ring for AKRON mechanisms 757073 N70 2-242.
