24V motor for monitor nozzles - repair assembly
Complete maintenance kit for motorization of monitor nozzles AKRON models including:
- ● 1 24V motor (Deutsch female connector[33560010] or Speed Clip[50770030])
- ● 1 O-ring 2-015 (757112)
- ● 1 O-ring 2-029(757056)
- ● 1 worm screw actuator(785021)
- ● 1 spring pin 1/16" x 3/8"(744341)
- ● 4 socket head cap screws 6-32 x 1/2"(765052)
Belt drive for rotation system - monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
39414 |
|
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
2 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
|
100 |
39412 |
ELEVATION STOP |
2 |
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
SOCKET HEAD CAP SCREW 767132 6-32 X 1 3/8
Hexagon socket head cap screws for AKRON mechanisms 6-32 X 1 3/8.
Spring 768167
Spring for AKRON mechanisms 768167 (1/2 OD X 1 3/4 LG)
Hex button head cap screw 765182
Hex socket button head head cap screw (full thread) for AKRON mechanisms 765182 18-8 SS 1/4-20X1
Drive mechanism with belt for elevation system - monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
55 |
- |
TEFLON SHOULDERED SPACER |
1 |
|
88 |
39151 |
|
1 |
|
94 |
- |
Notched pulley axle |
1 |
|
95 |
- |
pOULIE wheel |
1 |
|
96 |
- |
BELT |
1 |
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
Outlet elbow S/A for monitors StreamMaster 3578-3579
Maintenance/repair part: outlet elbow sub-assembly for monitors StreamMaster 3578 and 3579 with bosses [moulded mounting bracket (4 threaded holes)].
O-RING 757210 2-241
Nitrile rubber O-ring for AKRON mechanisms 757210 N70 2-241.
