Belt drive for rotation system - monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
39414 |
|
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
2 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
|
100 |
39412 |
ELEVATION STOP |
2 |
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
O-RING 757035 2-236
Nitrile rubber O-ring for AKRON N 2-236 mechanisms.
O-RING 757319 2-343
Nitrile rubber O-ring for AKRON N70 2-343 mechanisms.
ROLL PIN 744341 302 .0625 x .375
Stainless steel split cylindrical roll pin for AKRON 302 mechanisms .0625 x .375.
Chain for lifting mechanism
Lifting chain for AKRON mechanisms 35782014 7.875.
WORM GEAR ACTUATOR 5078 785021
5078 Teflon worm gear actuator for AKRON mechanisms.
O-RING PARKER BUNA 757358 2-154
Nitrile rubber O-ring for AKRON mechanisms 757358 N70 2-154.
Mounting flange for firefighting monitor StreamMaster
Maintenance/repair part: mounting flange 117823 for firefighting monitors StreamMaster 3570, 3578, 3579 and 3598.
