Gears: lifting mechanism for monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
52 |
- |
SHOULDER SLEEVE |
8 |
|
53 |
- |
HEXAGONAL SOCKET HEAD CAP SCREW WITH SHOULDER |
8 |
|
90 |
- |
AXIS OF ROTATION |
1 |
|
91 |
- |
PLANETARY GEAR |
8 |
|
92 |
- |
DRIVE SUPPORT |
1 |
|
93 |
- |
SHOULDERED SPACER |
1 |
O-RING 757073 2-242
Nitrile rubber O-ring for AKRON mechanisms 757073 N70 2-242.
O-RING 757020 2-120
Nitrile rubber O-ring for AKRON N70 2-120 mechanisms.
7:1 motor for firefighting monitors StreamMaster 3578-3579-3598
7:1 24V motor (ITT male connector) for elevation and rotation systems on firefighting monitors AKRON StreamMaster I 3578, 3579 and 3598 models.
O-RING 757244 2-030
O-ring for AKRON mechanisms 757244 1 3/4 X 1 5/8. 2-030 N-818-70 IMP.
Washer 784072 7/16x.200x.031
Stainless steel washer for AKRON mechanisms 784072 10 ST STL 7/16 X .200X .031T
Maintenance/repair kit - monitor StreamMaster II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
10 |
40590 |
|
1 |
|
11 |
32802 |
|
1 |
|
12 |
40591 |
|
1 |
|
13 |
33270 |
|
75 |
|
14 |
33798 |
|
2 |
|
15 |
33806 |
|
2 |
|
77 |
40340 |
|
1 |
|
78 |
40341 |
|
1 |
|
79 |
40342 |
|
1 |
|
80 |
33800 |
|
1 |
|
81 |
33802 |
|
1 |
|
82 |
- |
O-RING 2-348 |
1 |
O-RING 2-343
O-RING SEAL 2-241
O-RING SEAL 2-158
BALLS FOR 3/8" BEARING
FULL SCREW CAP
PIERCED SCREW CAP
TEFLON BEARING SEAL 4.835
TEFLON BEARING SEAL 4.185
O-RING SEAL 2-242
O-RING SEAL 2-246
O-RING 2-347To access the individual parts, please refer to the interactive table on the KIT CONTENTS
Hex socket head cap screw 767094 4-40 X 5/8
Stainless steel hex socket head cap screw (full thread) for AKRON mechanisms 767094 4-40 X 5/8.
