Shutoff handle 721122 for AFF, Marauder and TurboJet nozzles
AKRON 721122 shutoff handle for older versions of the following handheld nozzles models:
- AFF (models manufactured before 2000)
- Marauder
- TurboJet
Drive mechanism with belt for rotation system - monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
- |
NOTCHED PULLEY SHAFT |
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
1 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
O-RING 2-112
NEEDLE BEARING
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
Hex socket head cap screw 767186 1/4-20x2
Stainless steel hex socket head cap screw (full thread) for AKRON mechanisms 767186 1/4-20x2.
24V motor for 3293 and 5177 nozzles
24V motor (Deutsch [F] or Speed Clip connectors) for monitor nozzles AKRON AkroMatic 5177 and FireFox 3293 models.
HARDENED STEEL WORM GEAR 718273 HL1056
Boston Gear hardened steel worm gear for AKRON HL1056 mechanisms.
Square cut gasket 717042 (2-1/16 x 1-9/16 x 1/8)
Nitrile rubber gasket (square section ring) for AKRON mechanisms 717042 : 2-1/16X1-9/16X1/8 - N674-70
O-RING 757056 2-029
Nitrile rubber O-ring for AKRON N70 2-029 mechanisms.
SOLID SCREW-ON PLUG 742112 1/2-20 x 1/4
Celcon Delrin screw-on solid plug for AKRON mechanisms 742112 1/2-20 X 1/4.
