Belt drive for rotation system - monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
39414 |
|
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
2 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
|
100 |
39412 |
ELEVATION STOP |
2 |
NOTCHED PULLEY SHAFT
O-RING 2-112
NEEDLE BEARINGTo access the individual parts, please refer to the interactive table on the KIT CONTENTS
SCREW-ON HOLED PLUG 742023 3/8-24 X 3/16
Celcon Delrin screw-on drilled plug for AKRON mechanisms 742023 3/8-24 X 3/16.
Hex socket set screw with cup point 765002 1/4-20 x 1/4
Stainless steel hex socket set screw with cup point for AKRON mechanisms 765002 1/4-20 X 1/4.
Logic box U1 for monitors FireFox 3463 and Severe Duty 3491
Logic box U1 (with stow and oscillation functions) for the following monitors U1 models:
- FireFox 3463
- Severe Duty 3491
PLEASE CHECK THAT YOUR LOGIC BOX IS COMPATIBLE WITH YOUR Monitor
Wiring harness with position feedback for FireFox U2 monitor
Complete wiring harness with position feedback (Deutsch connectors) for the following U2 monitor models:
- FireFox 3463 and 3563
- Severe-Duty 3490 and 3491
BE SURE TO CHECK THE HARNESS'S COMPATIBILITY WITH YOUR Monitor
Hex socket head cap screw 763041 1/4 -20 X 1
Stainless steel hex socket head cap screw (full thread) for AKRON mechanisms 763041 1/4-20 X 1.
Actuator 51772021 (with 24V motor)
Actuator 51772021 U2 24V motor (Deutsch female connector) for monitor nozzles AKRON AkroMatic Styles 5175 and 5177.
O-ring 757376 (4-3/4 x 4-3/8) - 2-348
Nitrile rubber O-ring for AKRON mechanisms 757376: 4 3/4 X 4 3/8 BUNA N 70 2-348
