Hex socket set screw with dog point 767088 10-24 x 5/166
Stainless steel hex socket set screw with dog point for AKRON mechanisms 767088 10-24 x 5/166.
Hex socket set screw with cup point 765002 1/4-20 x 1/4
Stainless steel hex socket set screw with cup point for AKRON mechanisms 765002 1/4-20 X 1/4.
Mounting flange for firefighting monitor StreamMaster
Maintenance/repair part: mounting flange 117823 for firefighting monitors StreamMaster 3570, 3578, 3579 and 3598.
TEFLON BEARING SEAL 803058 4.835
Teflon bearing seal for AKRON mechanisms 803058 UHMW 4.835 ID.
Gears: rotation mechanism for monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
46 |
- |
AXIS OF ROTATION |
1 |
|
47 |
- |
TEFLON WORM SCREW |
1 |
|
48 |
34521 |
|
1 |
|
51 |
39138 |
7:1 PLANETARY GEAR |
3 |
|
52 |
- |
SHOULDER SLEEVE |
4 |
|
53 |
- |
HEXAGONAL SOCKET HEAD CAP SCREW WITH SHOULDER |
3 |
|
54 |
- |
PLANETARY GEAR RING |
1 |
|
55 |
- |
TEFLON SHOULDER SPACER |
1 |
SPRING PINTo access the individual parts, please refer to the interactive table on the KIT CONTENTS
O-RING 757329 2-121
Nitrile rubber O-ring for AKRON mechanisms 757329 N674-70 2-121.
HALF-MOON KEY 727025 1/8 X 1/2 404.
Woodruff stainless steel half-moon key for AKRON mechanisms 727025 1/8 X 1/2 404.
Hex socket head cap screw 765100 10-24X5/8
Stainless steel hexagonal socket head cap screw (full thread) for AKRON 765100 mechanisms 10-24X5/8.
