Elevation motor for firefighting monitors StreamMaster II 3480-3482
24V motor (Deutsch male connector) for elevation system on firefighting monitors AKRON StreamMaster II 3480 and 3482 models.
Belt drive for rotation system - monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
39414 |
|
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
2 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
|
100 |
39412 |
ELEVATION STOP |
2 |
NOTCHED PULLEY SHAFT
O-RING 2-112
NEEDLE BEARINGTo access the individual parts, please refer to the interactive table on the KIT CONTENTS
Hex socket head cap screw 765260 6-32 X 1
Stainless steel hex socket head cap screw (full thread) for AKRON mechanisms 765260 6-32 X 1.
BRONZE-SHOULDERED SPACER 703461
Shoulder spacer in bronze for AKRON 703461 mechanisms.
Narrow washer 784123 3/8 x .188
Stainless steel narrow washer for AKRON mechanisms 784123 88 SS NARROW 3/8 X .188 X
Square cut gasket 717042 (2-1/16 x 1-9/16 x 1/8)
Nitrile rubber gasket (square section ring) for AKRON mechanisms 717042 : 2-1/16X1-9/16X1/8 - N674-70
Power wiring harness for Akron U2 monitors
This power harness (U2) supplies power to the Akron monitor control unit by connecting it to a vehicle.
Compatible U2 models:
- AeroMaster 12 - Style 3000
- Electric Ladder Pipe - Style 1494
- StreamMaster II - Style 3480
- StreamMaster II - Style 3482
BE SURE TO CHECK THAT THE HOSE ASSEMBLY IS COMPATIBLE WITH YOUR Monitor
O-RING 757446 2-347
Nitrile rubber O-ring for AKRON mechanisms 757446 N70 2-347.
