Rotation gearbox with motor and manual override for Gemini 3476 monitor
Rotation gearbox with hydraulic motor and manual override for firefighting monitor AKRON Gemini 3476.
SHIM WASHER 769494 STL.010
Lock washer for AKRON mechanisms 769494 STL.010.
Belt drive for rotation system - monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
39414 |
|
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
2 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
|
100 |
39412 |
ELEVATION STOP |
2 |
NOTCHED PULLEY SHAFT
O-RING 2-112
NEEDLE BEARINGTo access the individual parts, please refer to the interactive table on the KIT CONTENTS
O-RING 757327 2-153
Nitrile rubber O-ring for AKRON mechanisms 757327 BUNA N70 N70 3 11/16 OD X 3 1/2 ID 2-153.
24V (7:1) motor for Trident firefighting monitor
24V motor (Deutsch female connector), ratio 7:1, for the following firefighting monitor AKRON model:
- Monitor Trident 3356
O-ring 757471 - 2-349
Viton rubber O-ring for AKRON mechanisms 757471: ELEV VITON 70 DURO 2-349
O-RING 757210 2-241
Nitrile rubber O-ring for AKRON mechanisms 757210 N70 2-241.
Hex socket set screw with cup point 766015 1/4-20 x 5/16
Stainless steel hex socket set screw with cup point for AKRON mechanisms 766015 1/4-20 X 5/16.
