Repair kit: position sensor for worm gear - monitor Stream Master II (3480-3482)
Detailed content :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
65 |
- |
WORM WHEEL |
1 |
|
66 |
34523 |
|
1 |
|
67 |
- |
MAGNET |
1 |
O-RING SEAL 2-120
To access the individual parts, please refer to the interactive table in the KIT CONTENTS tab
O-ring 757335 - 2-122
Nitrile rubber O-ring for AKRON mechanisms 757335: BUNA N 674-70 2-122
Spring 768167
Spring for AKRON mechanisms 768167 (1/2 OD X 1 3/4 LG)
Square cut gasket 717042 (2-1/16 x 1-9/16 x 1/8)
Nitrile rubber gasket (square section ring) for AKRON mechanisms 717042 : 2-1/16X1-9/16X1/8 - N674-70
Inlet elbow for monitors StreamMaster 3578-3579
Maintenance/repair part: inlet elbow 121570 for monitor StreamMaster 3578 and 3579 (no magnet).
10-TOOTH PINION 769499 X1/2 BORE X35
10-tooth sprocket for AKRON mechanisms 769499 X1/2 BORE X35.
Hex socket head cap screw 767019 4-40 x 3/8
Stainless steel hex socket head cap screw (full thread) for AKRON mechanisms 767019 4-40 X 3/8.
O-RING 757327 2-153
Nitrile rubber O-ring for AKRON mechanisms 757327 BUNA N70 N70 3 11/16 OD X 3 1/2 ID 2-153.
