PLANETARY GEAR 35780371 (elevation)
7:1 planetary gear set (without shaft) for AKRON elevation mechanisms 35780371.
Hex socket set screw with dog point 767088 10-24 x 5/166
Stainless steel hex socket set screw with dog point for AKRON mechanisms 767088 10-24 x 5/166.
O-RING 757326 2-158
Nitrile rubber O-ring for AKRON mechanisms 757326 N70 2-158.
Hex socket head cap screw 765014 1/4-20x1/2
Stainless steel hex socket head cap screw (full thread) for AKRON mechanisms 765014 1/4-20X1/2.
HALF-MOON KEY 727025 1/8 X 1/2 404.
Woodruff stainless steel half-moon key for AKRON mechanisms 727025 1/8 X 1/2 404.
NEEDLE BEARING 704437 3/8ID NTA613
Needle bearing for AKRON 704437 3/8ID NTA613 mechanisms.
Gears: rotation mechanism for monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
46 |
- |
AXIS OF ROTATION |
1 |
|
47 |
- |
TEFLON WORM SCREW |
1 |
|
48 |
34521 |
|
1 |
|
51 |
39138 |
7:1 PLANETARY GEAR |
3 |
|
52 |
- |
SHOULDER SLEEVE |
4 |
|
53 |
- |
HEXAGONAL SOCKET HEAD CAP SCREW WITH SHOULDER |
3 |
|
54 |
- |
PLANETARY GEAR RING |
1 |
|
55 |
- |
TEFLON SHOULDER SPACER |
1 |
SPRING PINTo access the individual parts, please refer to the interactive table on the KIT CONTENTS
24V motor for monitor nozzles - repair assembly
Complete maintenance kit for motorization of monitor nozzles AKRON models including:
- ● 1 24V motor (Deutsch female connector[33560010] or Speed Clip[50770030])
- ● 1 O-ring 2-015 (757112)
- ● 1 O-ring 2-029(757056)
- ● 1 worm screw actuator(785021)
- ● 1 spring pin 1/16" x 3/8"(744341)
- ● 4 socket head cap screws 6-32 x 1/2"(765052)
