24V motor for monitor nozzles - repair assembly
Complete maintenance kit for motorization of monitor nozzles AKRON models including:
- ● 1 24V motor (Deutsch female connector[33560010] or Speed Clip[50770030])
- ● 1 O-ring 2-015 (757112)
- ● 1 O-ring 2-029(757056)
- ● 1 worm screw actuator(785021)
- ● 1 spring pin 1/16" x 3/8"(744341)
- ● 4 socket head cap screws 6-32 x 1/2"(765052)
Drive mechanism with belt for rotation system - monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
- |
NOTCHED PULLEY SHAFT |
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
1 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
O-RING 2-112
NEEDLE BEARING
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
7:1 motor for firefighting monitors StreamMaster 3578-3579-3598
7:1 24V motor (ITT male connector) for elevation and rotation systems on firefighting monitors AKRON StreamMaster I 3578, 3579 and 3598 models.
O-RING 757295 2-110
O-ring for AKRON mechanisms 757295 2-110.
NEEDLE BEARING 704395 1/2ID INASCE86
Needle roller bearing for AKRON 1/2ID INASCE86 mechanisms.
LIMIT SWITCH 34400003
Stroke limiter (Deutsch plug) for monitor AKRON DeckMaster 3440.
RECTANGULAR KEY 727044 1018 SPEC ST
Rectangular key for AKRON mechanisms 727044 1018 SPEC ST.
Lubricating grease for AKRON mechanisms
IRIX EVO CSX 100-2 FG food-grade lubricating grease for greasing and lubricating AKRON parts and mechanisms.
