7:1 motor for firefighting monitors StreamMaster 3578-3579-3598
7:1 24V motor (ITT male connector) for elevation and rotation systems on firefighting monitors AKRON StreamMaster I 3578, 3579 and 3598 models.
CHROME-PLATED WORM GEAR .189 118528
Chrome-plated steel worm screw for AKRON 118528 mechanisms.
Drive mechanism with belt for rotation system - monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
- |
NOTCHED PULLEY SHAFT |
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
1 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
O-RING 757205 2-229
Nitrile rubber O-ring for AKRON mechanisms 757205 BUNA N70 2 5/8 X 2 3/8 2-229.
6052 controller for monitor StreamMaster II
6052 controller module for StreamMaster II firefighting monitor (3480 and 3482 models).
PIERCED SCREW CAP 742123 1/2 -20X1/4
Celcon Delrin screw-on drilled plug for AKRON mechanisms 742123 1/2-20 X 1/4.
Hex socket head cap screw 767126 10-24 X 1 3/4
Stainless steel hex socket head cap screw (partial thread) for AKRON mechanisms 767126 10-24 X 1 3/4 LG.
Inlet elbow for monitors StreamMaster 3578-3579
Maintenance/repair part: inlet elbow 121570 for monitor StreamMaster 3578 and 3579 (no magnet).
