Hex socket head cap screw 765100 10-24X5/8
Stainless steel hexagonal socket head cap screw (full thread) for AKRON 765100 mechanisms 10-24X5/8.
Hex head cap screw 761082
Stainless steel hex head cap screw (full thread) for AKRON mechanisms 761082 5/16-18x1/2.
Rotating mechanism for monitor DeckMaster (3440)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
13 |
34839 |
|
1 |
|
73 |
34478 |
|
2 |
|
74 |
34479 |
|
2 |
|
75 |
34481 |
|
1 |
|
76 |
34279 |
|
1 |
|
77 |
34471 |
|
1 |
|
79 |
34473 |
|
1 |
|
80 |
34397 |
|
2 |
|
81 |
34398 |
|
1 |
|
82 |
34472 |
|
1 |
|
137 |
34476 |
|
2 |
|
138 |
34475 |
|
2 |
|
139 |
34428 |
|
2 |
HARDENED STEEL WORM SCREW
HALF-MOON KEY
10-TOOTH PINION
THICK ACETAL SPACER
O-RING 2-112
CHAIN FOR ROTATION MECHANISM
SHAFT FOR ROTATION MECHANISM
SPRING WASHER
LOCK WASHER
BRACE WITH BRONZE SHOULDERS
THIN BEARING WASHER
THICK BEARING WASHER
NEEDLE ROLLER THRUST BEARINGTo access the individual parts, please refer to the interactive table on the KIT CONTENTS
O-ring 757112 (11/16 x 9/16) - 2-015
Nitrile rubber O-ring for AKRON mechanisms 757112: 11/16 X 9/16 2-015
SHIM WASHER 769494 STL.010
Lock washer for AKRON mechanisms 769494 STL.010.
Hex socket set screw with cup point 766015 1/4-20 x 5/16
Stainless steel hex socket set screw with cup point for AKRON mechanisms 766015 1/4-20 X 5/16.
Chain for lifting mechanism
Lifting chain for AKRON mechanisms 35782014 7.875.
Rotation mechanism 3578-0201 - 5:1 planetary gear (12 teeth)
AKRON 3578-0201 rotation sub-assembly - complete system with 2 planetary gear plates (5:1 - 12 teeth) and rotation shaft for monitor StreamMaster XT 3598 (including U2 version).
