24V (5:1) motor for Firefox and StreamMaster firefighting monitors
24V motor (Deutsch female connector), ratio 5:1, for the following firefighting monitors AKRON models:
- Monitor-turret 3353
- FireFox 3463, 3563
- StreamMaster I 3572, 3578, 3579 and 3598
Screw-on plug (with hole) 742123 1/2 -20X1/4
Celcon Delrin screw-on plug (with hole) for AKRON mechanisms 742123 1/2-20 X 1/4.
THICK THRUST WASHER 784130 0.126 TRD1220
Thick thrust washer for AKRON mechanisms 784130 0.126 TRD1220.
Hex socket head cap screw 767133 10-24X3
Stainless steel hex socket head cap screw (partial thread) for AKRON mechanisms 767133 10-24x3.
Gears: lifting mechanism for monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
52 |
- |
SHOULDER SLEEVE |
8 |
|
53 |
- |
HEXAGONAL SOCKET HEAD CAP SCREW WITH SHOULDER |
8 |
|
90 |
- |
AXIS OF ROTATION |
1 |
|
91 |
- |
PLANETARY GEAR |
8 |
|
92 |
- |
DRIVE SUPPORT |
1 |
|
93 |
- |
SHOULDERED SPACER |
1 |
Belt drive for rotation system - monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
39414 |
|
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
2 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
|
100 |
39412 |
ELEVATION STOP |
2 |
NOTCHED PULLEY SHAFT
O-RING 2-112
NEEDLE BEARINGTo access the individual parts, please refer to the interactive table on the KIT CONTENTS
Roll pin 744078
Stainless steel split cylindrical roll pin for AKRON mechanisms 744078: ESN ST STL 18-879-022-094-0750
Inlet elbow for monitors StreamMaster II 3480-3482
Maintenance/repair part: inlet elbow for monitors StreamMaster II 3480 and 3482.
