Inlet elbow for monitors StreamMaster II 3480-3482
Maintenance/repair part: inlet elbow for monitors StreamMaster II 3480 and 3482.
Hex socket set screw with cup point 765002 1/4-20 x 1/4
Stainless steel hex socket set screw with cup point for AKRON mechanisms 765002 1/4-20 X 1/4.
CRANTED PULLEY SHAFT (FOR OPTIONAL HANDWHEEL)
Toothed pulley shaft (for handwheel option only) for AKRON 7:1 MCH COMP mechanisms.
Narrow washer 784123 3/8 x .188
Stainless steel narrow washer for AKRON mechanisms 784123 88 SS NARROW 3/8 X .188 X
2.5" outlet elbow for monitor StreamMaster II 3482
Maintenance/repair part: outlet elbow for StreamMaster II 3482 monitor.
Hex socket set screw with cup point 765042 8-32 X 3/16
Stainless steel hex socket set screw with cup point for AKRON mechanisms 765042 8-32 X 3/16.
Rotating mechanism for monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
35 |
- |
TEFLON SPACER |
1 |
|
36 |
34397 |
|
1 |
|
37 |
32804 |
|
4 |
|
38 |
33649 |
|
2 |
|
39 |
34478 |
|
1 |
|
40 |
34839 |
|
1 |
|
42 |
- |
SOCKET HEAD CAP SCREW |
4 |
|
43 |
32790 |
|
1 |
|
47 |
- |
TEFLON WORM SCREW |
1 |
|
48 |
34521 |
|
1 |
|
49 |
- |
OBTURATOR |
1 |
SPRING WASHER
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
PLANETARY GEAR 7:1 718262
Planetary gears for AKRON 7:1 RATIO SLT XT mechanisms.
