Inlet elbow repair pack for StreamMaster 3578 and 3579
Maintenance/repair parts pack: repair pack for inlet elbow (elbow 121570 + magnet 731081) for firefighting monitors StreamMaster 3578 and 3579.
Hex socket head cap screw 763077 10-24X2
Stainless steel hex socket head cap screw (partial thread) for AKRON mechanisms 763077 10-24X2.
Elevation motor for firefighting monitors StreamMaster II 3480-3482
24V motor (Deutsch male connector) for elevation system on firefighting monitors AKRON StreamMaster II 3480 and 3482 models.
6052 controller for monitor StreamMaster II
6052 controller module for StreamMaster II firefighting monitor (3480 and 3482 models).
Gears: rotation mechanism for monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
46 |
- |
AXIS OF ROTATION |
1 |
|
47 |
- |
TEFLON WORM SCREW |
1 |
|
48 |
34521 |
|
1 |
|
51 |
39138 |
7:1 PLANETARY GEAR |
3 |
|
52 |
- |
SHOULDER SLEEVE |
4 |
|
53 |
- |
HEXAGONAL SOCKET HEAD CAP SCREW WITH SHOULDER |
3 |
|
54 |
- |
PLANETARY GEAR RING |
1 |
|
55 |
- |
TEFLON SHOULDER SPACER |
1 |
SPRING PINTo access the individual parts, please refer to the interactive table on the KIT CONTENTS
NEEDLE BEARING 703523 3/4ID BA128ZOH
Needle roller bearing for AKRON 3/4ID BA128ZOH mechanisms.
O-RING 757073 2-242
Nitrile rubber O-ring for AKRON mechanisms 757073 N70 2-242.
PLANETARY GEAR 35780371 (elevation)
7:1 planetary gear set (without shaft) for AKRON elevation mechanisms 35780371.
