Rotation mechanism 3578-0201 - 5:1 planetary gear (12 teeth)
AKRON 3578-0201 rotation sub-assembly - complete system with 2 planetary gear plates (5:1 - 12 teeth) and rotation shaft for monitor StreamMaster XT 3598 (including U2 version).
Shutoff handle 721122 for AFF, Marauder and TurboJet nozzles
AKRON 721122 shutoff handle for older versions of the following handheld nozzles models:
- AFF (models manufactured before 2000)
- Marauder
- TurboJet
O-ring 757042 (7/8 x 3/4) - 2-018
Nitrile rubber O-ring for AKRON mechanisms 757042: 7/8 X 3/4 BUNA N70 2-018
Rotation gearbox with motor and manual override for Gemini 3476 monitor
Rotation gearbox with hydraulic motor and manual override for firefighting monitor AKRON Gemini 3476.
Pattern sleeve with control ring 17450017
Maintenance/repair part: pattern sleeve with control ring for TurboMaster 1745 v1 nozzle.
24V (5:1) motor for firefighting monitors FireFox and StreamMaster - repair kit
Repair kit for firefighting monitors Akron FireFox and StreamMaster including 24V motor (ITT male connector), 5:1 ratio, with 2 O-rings.
Compatible with the following AKRON firefighting monitors models:
- FireFox 3463
- StreamMaster I 3578, 3579 and 3598
Belt drive for rotation system - monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
39414 |
|
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
2 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
|
100 |
39412 |
ELEVATION STOP |
2 |
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
7:1 motor for firefighting monitors StreamMaster 3578-3579-3598
7:1 24V motor (ITT male connector) for elevation and rotation systems on firefighting monitors AKRON StreamMaster I 3578, 3579 and 3598 models.
