Gears: rotation mechanism for monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
46 |
- |
AXIS OF ROTATION |
1 |
|
47 |
- |
TEFLON WORM SCREW |
1 |
|
48 |
34521 |
|
1 |
|
51 |
39138 |
7:1 PLANETARY GEAR |
3 |
|
52 |
- |
SHOULDER SLEEVE |
4 |
|
53 |
- |
HEXAGONAL SOCKET HEAD CAP SCREW WITH SHOULDER |
3 |
|
54 |
- |
PLANETARY GEAR RING |
1 |
|
55 |
- |
TEFLON SHOULDER SPACER |
1 |
SPRING PINTo access the individual parts, please refer to the interactive table on the KIT CONTENTS
Hex socket head cap screw 767094 4-40 X 5/8
Stainless steel hex socket head cap screw (full thread) for AKRON mechanisms 767094 4-40 X 5/8.
Belt drive for rotation system - monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
39414 |
|
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
2 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
|
100 |
39412 |
ELEVATION STOP |
2 |
NOTCHED PULLEY SHAFT
O-RING 2-112
NEEDLE BEARINGTo access the individual parts, please refer to the interactive table on the KIT CONTENTS
Washer 784072 7/16x.200x.031
Stainless steel washer for AKRON mechanisms 784072 10 ST STL 7/16 X .200X .031T
THICK BEARING WASHER 784113 0.94 TRC613
Thick bearing washer for AKRON mechanisms 784113 0.94 TRC613.
ELEVATION BEARING HUB 116465 SER.06SF
Lift bearing hub for AKRON mechanisms 116465 SER.06SF.
Flat washer 784075 1/4x5/80x3/64
Thick stainless steel flat washer for AKRON mechanisms 784075 1/4DX5/80DX3/64 THK STSTL
O-RING 757056 2-029
Nitrile rubber O-ring for AKRON N70 2-029 mechanisms.
