Rotating mechanism for monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
35 |
- |
TEFLON SPACER |
1 |
|
36 |
34397 |
|
1 |
|
37 |
32804 |
4 |
|
|
38 |
33649 |
2 |
|
|
39 |
34478 |
1 |
|
|
40 |
34839 |
1 |
|
|
42 |
- |
SOCKET HEAD CAP SCREW |
4 |
|
43 |
32790 |
1 |
|
|
47 |
- |
TEFLON WORM SCREW |
1 |
|
48 |
34521 |
1 |
|
|
49 |
- |
OBTURATOR |
1 |
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
O-RING 757035 2-236
Nitrile rubber O-ring for AKRON N 2-236 mechanisms.
Shoulder spacer in bronze 768376
Shoulder spacer in bronze for AKRON mechanisms 768376.
NEEDLE BEARING 704437 3/8ID NTA613
Needle bearing for AKRON 704437 3/8ID NTA613 mechanisms.
Motor for firefighting monitor DeckMaster 3440 (elevation / rotation)
24V motor for elevation and rotation systems from firefighting monitor AKRON DeckMaster 3440 (U1 version with ITT male connector, U2 version with Deutsch female connector).
Belt drive for rotation system - monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
39414 |
|
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
2 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
|
100 |
39412 |
ELEVATION STOP |
2 |
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
Hex socket head cap screw 763077 10-24X2
Stainless steel hex socket head cap screw (partial thread) for AKRON mechanisms 763077 10-24X2.
Washer 784072 7/16x.200x.031
Stainless steel washer for AKRON mechanisms 784072 10 ST STL 7/16 X .200X .031T
