Drive mechanism with belt for rotation system - monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
- |
NOTCHED PULLEY SHAFT |
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
1 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
O-RING 2-112
NEEDLE BEARING
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
SHAFT FOR ROTATION MECHANISM 769938
Rotating shaft for AKRON mechanisms 769938.
Position sensor 34630228
Position sensor (Deutsch plug) for monitors AKRON DeckMaster 3440 (U1), FireFox 3463 and StreamMaster I (3578 and 3579).
O-RING 757035 2-236
Nitrile rubber O-ring for AKRON N 2-236 mechanisms.
O-ring 757242 (1-5/16 x 3/16) - 2-025
Nitrile rubber O-ring for AKRON mechanisms 757242: 1 5/16 X 3/16 N-818-70 IM 2-025
Square cut gasket 715016 (2-29/32 x 2-3/64)
Nitrile rubber gasket (square-section ring) for AKRON mechanisms 715016 : 2 29/32 X 2 3/64 - V 671
Wiring harness for StreamMaster 3578 monitor (U1 - U2)
Complete wiring harness for the StreamMaster 3578 monitor (SpeedClip, ITT, and Deutsch connectors).
BE SURE TO CHECK THAT THE HARNESS IS COMPATIBLE WITH YOUR Monitor
Stop screw 767078
Stainless steel slotted head stop screw for AKRON mechanisms 767078.
