Copy of Handheld multi-flow nozzle TurboJet 1733

logo SOLASFM Approved

The TurboJet 1733 from AKRON BRASS is a handheld multi-flow nozzle designed to combine attack, protection, and cooling in the field. Its constant-flow system allows you to easily select 475, 550, 750, or 950 L/min while maintaining high spray quality. With its pistol grip, handle control, and rotary adjustment, it remains easy to maneuver during operations. The handheld nozzle complies with EN 15182 Type 3, is FM-certified, has an effective range of 40 m , and produces a wide 120° spray pattern.

Read moreShow less
Reference:
41145
Guide de tailles
Inlet diameter
Out of stock (lead time: please contact us)
Create a quote
€912.75 (tax excl.)
€912.75 (tax excl.)

Partager cette fiche produit :

Add to compare0
Description

handheld nozzle designed for jobs that demand power and flexibility

The handheld multi-flow nozzle TurboJet 1733 fromAKRON BRASS is designed for users looking for a professional handheld nozzle that combines hydraulic power, versatility and ease of use. Its constant flow operation maintains a consistent response whatever the setting selected, while offering rapid adaptation to the situation encountered. This positioning makes it a relevant reference for fire departments, industry and sites with high operational demands.

Technical specifications

Features Description
Model

AKRON BRASS TurboJet 1733

Type

Handheld nozzle type 3 With adjustable stream, with selectable constant flow rate

Available flow rates

475, 550, 750 and 950 L/min

Reference pressure

950 L/min @ 7 bar

Effective range

40 meters

Spray pattern

From straight to wide spray, with a spray angle of up to 120°

Opening / closing

Handle control with ball valve

Hand grip

Pistol grip

Weight

3.1 kg

Compliance

EN 15182-2:2007+A1:2009, type 3

Certification

FM Approvals

Manufacturer's warranty

10 years

Four settings to adapt hydraulic response to the situation

The TurboJet 1733 offers four flow settings: 475, 550, 750 and 950 L/min. This range makes it possible to quickly adjust the quantity of water used according to the context of intervention, the firefighter, the available supply or the nature of the fire. The operational advantage is that the same handheld nozzle can be used to cover several different needs, without having to change equipment.

In concrete terms, this modularity makes it possible to :

  • rapidly reduce or increase flow, depending on the phase of intervention;
  • adapt response to available hydraulic potential;
  • greater flexibility on sites with different configurations;
  • use the same handheld nozzle for control, protection or more sustained attack.

Straight jet, wide spread jet: a response adapted to several intervention phases

The quality of a handheld nozzle spray does not depend solely on its flow rate. The TurboJet 1733 allows you to switch from a straight jet to a wide diffused jet of up to 120°. In straight jet mode, it is ideal for long-distance applications, with an effective reach of 40 meters. In wide diffused spray, it meets other tactical needs, such as protection, cooling or progression.

Depending on the situation, this versatility is useful for :

  • attacking a focus with a search for effective range ;
  • cooling volumes, structures or hot spots;
  • protecting responders from thermal radiation;
  • creating a water screen;
  • progress in degraded environments.

A design made to last in fire department

The handheld nozzle is easy to handle thanks to its pistol grip and handle control. Flow rate and spray pattern are adjusted by means of rotating elements, for direct, robust operation. The data sheet also gives a length of 292 mm and a weight of 3.1 kg, making the product's positioning even clearer.

Numbers aside, the TurboJet 1733 is in keeping with the AKRON BRASS philosophy:

  • a design conceived for sustained professional use ;
  • maneuverability adapted to the constraints of the field;
  • repeatability of settings;
  • credibility reinforced by conformity and certification.

The handheld nozzle is certified to EN 15182 type 3, is included in the scope of the FM Approvals certificate supplied, and benefits from AKRON's 10-year warranty program applicable to handheld nozzles TurboJet.

The right choice for fire brigades, industry and high-risk sites

This model is a natural choice for fire brigades, industrial fire departments, logistics platforms, petrochemical sites and sensitive installations. Its versatility enables it to cover several operational scenarios with a single reference.

This handheld nozzle can be particularly useful for :

  • machinery and facilities requiring a multi-purpose, high-flow handheld nozzle;
  • industrial environments where requirements vary from zone to zone;
  • sites looking for certified, technically credible equipment;
  • organizations wishing to standardize part of their equipment.

MMF and AKRON: a coherent choice for professional needs

Choosing this reference via MMF Protection et Sécuritémeans relying on an offer geared to needs in the field, and on a sound knowledge of fire-fighting equipment for professionals. The combination ofAKRON BRASS 's expertise and MMF's support enables you to choose a solution that is consistent with the operating, maintenance and availability constraints expected by professional users.

FAQ

What's the difference between a multi-flow handheld nozzle and a variable-flow handheld nozzle?

A multi-flow handheld nozzle offers several predefined flow positions, whereas a variable-flow handheld nozzle generally enables more continuous adjustment. The former favors simplicity, speed and repeatability in the field.

Is this handheld nozzle suitable for use in industrial environments?

Yes, its versatility, different flow settings, compliance and certification make it a relevant solution for many industrial contexts where needs can change rapidly.

Why are certification and conformity important for this type of equipment?

They provide objective benchmarks for evaluating equipment intended for demanding use. For a public or industrial purchaser, they contribute to the technical credibility of the product and the security of choice.

Read moreShow less
Product Details
41145

Data sheet

Material
Pyrolite
Length
156 mm
Weight
1.2 kg
Manufacturer's warranty
10 years
Inlet diameter
1.5" (DN40) BSP
1.5" (DN40) NH
2.5 " (DN 65) BSP
2.5 " (DN 65) NH
2.5" (DN65)
Certification
US: NFPA 1964
Available data rates:
360, 475, 550, 660, or 750 L/min @ 7 bar
475, 550, 660, or 750 L/min @ 5 bar
550, 610, 660, or 700 L/min @ 3.5 bar

Specific References

MPN
48664012
Attachments
Ecl_Tech_4866_127211
Technical Exploded View - AKRON Assault 48661733 handheld nozzle head (through May 2019)
Download (1.5MB)
guide-handheld nozzles-akron
Assembly Guide - AKRON Hand- handheld nozzles
Download (1.05MB)
