2.5" outlet elbow for monitor StreamMaster II 3482
Maintenance/repair part: outlet elbow for StreamMaster II 3482 monitor.
HALF-MOON KEY 727025 1/8 X 1/2 404.
Woodruff stainless steel half-moon key for AKRON mechanisms 727025 1/8 X 1/2 404.
Drive mechanism with belt for rotation system - monitor Stream Master II (3480-3482)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
- |
NOTCHED PULLEY SHAFT |
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
1 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
O-RING 2-112
NEEDLE BEARING
To access the individual parts, please refer to the interactive table on the KIT CONTENTS
Rotating mechanism for monitor DeckMaster (3440)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
13 |
34839 |
|
1 |
|
73 |
34478 |
|
2 |
|
74 |
34479 |
|
2 |
|
75 |
34481 |
|
1 |
|
76 |
34279 |
|
1 |
|
77 |
34471 |
|
1 |
|
79 |
34473 |
|
1 |
|
80 |
34397 |
|
2 |
|
81 |
34398 |
|
1 |
|
82 |
34472 |
|
1 |
|
137 |
34476 |
|
2 |
|
138 |
34475 |
|
2 |
|
139 |
34428 |
|
2 |
HARDENED STEEL WORM SCREW
HALF-MOON KEY
10-TOOTH PINION
THICK ACETAL SPACER
O-RING 2-112
CHAIN FOR ROTATION MECHANISM
SHAFT FOR ROTATION MECHANISM
SPRING WASHER
LOCK WASHER
BRACE WITH BRONZE SHOULDERS
THIN BEARING WASHER
THICK BEARING WASHER
NEEDLE ROLLER THRUST BEARINGTo access the individual parts, please refer to the interactive table on the KIT CONTENTS
Hex socket head cap screw 765014 1/4-20x1/2
Stainless steel hex socket head cap screw (full thread) for AKRON mechanisms 765014 1/4-20X1/2.
RING GEAR FOR ELEVATION 718164
Planetary gear for AKRON 718164 lifting mechanism.
SOCKET HEAD CAP SCREW 767132 6-32 X 1 3/8
Hexagon socket head cap screws for AKRON mechanisms 6-32 X 1 3/8.
Hex button head cap screw 765182
Hex socket button head head cap screw (full thread) for AKRON mechanisms 765182 18-8 SS 1/4-20X1
