Belt drive for rotation system - monitor Stream Master II (3480-3482 with handwheel)
Detailed contents :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
29 |
- |
85-TOOTH BELT |
1 |
|
56 |
39414 |
|
1 |
|
57 |
- |
PULLEY WHEEL |
1 |
|
58 |
34279 |
|
2 |
|
59 |
32809 |
|
1 |
|
60 |
- |
O-RING 2-164 |
1 |
|
100 |
39412 |
ELEVATION STOP |
2 |
NOTCHED PULLEY SHAFT
O-RING 2-112
NEEDLE BEARINGTo access the individual parts, please refer to the interactive table on the KIT CONTENTS
NEEDLE BEARING 704941 3/8ID B-67
Needle roller bearing for AKRON mechanisms 704941 3/8ID B-67.
O-RING 757446 2-347
Nitrile rubber O-ring for AKRON mechanisms 757446 N70 2-347.
THIN BEARING WASHER 784114 0.63 TRB613
Thin bearing washer for AKRON mechanisms 784114 0.63 TRB613.
NEEDLE ROLLER CLUTCH 703453 NTA-815 1/2ID
Torrington needle bearing for AKRON NTA-815 1/2ID mechanisms.
CRANTED PULLEY SHAFT (FOR OPTIONAL HANDWHEEL)
Toothed pulley shaft (for handwheel option only) for AKRON 7:1 MCH COMP mechanisms.
Repair kit: position sensor for worm gear - monitor Stream Master II (3480-3482)
Detailed content :
|
Part no |
Ref. MMF |
Designation |
Quantity included |
|
65 |
- |
WORM WHEEL |
1 |
|
66 |
34523 |
|
1 |
|
67 |
- |
MAGNET |
1 |
O-RING SEAL 2-120
To access the individual parts, please refer to the interactive table in the KIT CONTENTS tab
O-RING 757312 2-036
Nitrile rubber O-ring for AKRON N 2-036 mechanisms.
